MAPB46SH Heavy Duty Axial Piston Motor
Heavy Duty Axial Piston Motors
MAPB46SH Heavy Duty Axial Piston Motor
Heavy Duty Axial Piston Motors
Повече информация за продукта
Displacement [cm3/rev] | 47,13 |
Max. Speed [RPM] | 4000 (cont.) – 4500 (int.*) |
Max. Torque*** [Nm] | 263 (cont.) – 315 (int.**) |
Max. Output Power [kW] | 76 (cont.) – 110 (int.**) |
Max. Pressure [bar] | 350 (cont.) – 420 (int.**) |
Max. Oil Flow [lpm] | 189 (cont.) – 212 (int.*) |
Permissibble Shaft Load [N] | Max. 2000 (axial****) – max. 3600 (radial****) |
Min. Speed [RPM] | 500 |
Max. Pressure in Drain Line [bar] | 5 - Open drain line is always required |
Motor shaft is "SH" type. Please kindly check catalogue for specifications. Different shaft options are also available.
* Intermittent speed (flow) is for pressure up to 150 bar.
** Intermittent load: the permissible values may occur for max. 10% of every minute.
*** Theoretical torque
**** The calculated max values are based on the optimal direction of the forces Fr (radial force), Fa (axial force) and optimal position of the shaft.
